Miller columns

Welcome to your new lab, here's the instructions for each exercise :

• Read the lesson entirely!!!!
• Identify your learning goals.
• Understand the context.
• Follow the steps and rules carefully.
• Commit ONLY the files that are indicated.

You must try to find documentation and solution by yourself. The course contains links to references and a lot of other interesting websites. Don't forget : the web is your friend ;-)

Bon courage...

What are miller columns?

Like always, wikipedia has the answer ;-)

In this lab we'll create a file browser displaying infos as miller columns.

You can have a look at the existing files before starting...

First class!

Learning goals

1. Know how to call static method and understand the principle of a Singleton.
2. Know how to create simple abstract classes.
3. Know how to manipulate paths strings and be OS agnostic.

Context

Because our file browser file have to manipulate files and directories, we'll create an abstract class that can represent both. We'll call it a MillerPath.

Steps

• Before we start, let's get the root path from configuration file. Use the Config class correctly and set the value of $rootPath in public/index.php at line 11. Change the value in config.json if you need to.
• Create an abstract class named MillerPath in model/MillerPath.class.php.
• Add a private property named path, it will represent the absolute path of the directory or the file.
• Add a private property named parentPath, it will represent the absolute path of the parent directory of the directory or the file.
• Add a private property named name, it will represent name (last part of the path) of the directory or the file.
• Add a constructor that takes an absolute path as only argument and sets the path, parentPath and name properties correctly.You'll have to retrieve the last part of the path to get the name. Parent path will also be quick to retrieve.
• Add the appropriate getters for your properties : getPath, getParentPath and getName. If you use a decent IDE, it should be able to generate them ;-)
• Override the __toString method and return the name.
• Uncomment the parts of the code that needs to.

Files to edit

• model/MillerPath.class.php
• view/layout.php
• view/directory.php

Files...

Learning goals

1. Know how to inherit from an abstract class.
2. Know how to get mime type from for a given file.

Context

Now that we have a MillerPath, we can create a MillerFile that inherits from it.

Steps

• Create a class named MillerFile in model/MillerFile.class.php that inherits from the MillerPath class.
• Add a private property named mimeType, it will contain the mime type of the file.
• Override the constructor so you can initialize the mime type. Don't forget to call the parent's constructor at the beginning.
• Add the appropriate getter for your property : getMimeType.
• Uncomment the parts of the code that needs to.

Files to edit

• model/MillerFile.class.php
• view/layout.php
• view/directory.php

...Directories

Learning goals

1. Know how to inherit from an abstract class.
2. Know how to sort an array using a custom compare function.

Context

Now that we have a MillerPath, we can create a MillerDirectory that inherits from it.

Steps

• Create a class named MillerDirectory in model/MillerDirectory.class.php that inherits from the MillerPath class.
• Add a private property named directories, it will contain an array of MillerDirectory.
• Add a private property named files, it will contain an array of MillerFile.
• Add a private method name readDir that initializes the directories and files. Just iterate over the contents of the current directory. Detect if it's a directory or an item, create a new MillerDirectory or a new MillerFile and add it to the correct private array directories or files.
• Before ending this function sort the directories or files. Sort them by name. Your sort must be case insensitive and should not be troubled by hidden dirs and files. This means that .gnome should be treated as gnome.
• Add the appropriate getters for your properties : getDirectories and getFiles. If the private properties aren't already set up, just call the readDir function in this getters.
• Uncomment the parts of the code that needs to.

Files to edit

• model/MillerDirectory.class.php
• view/layout.php
• view/directory.php

Finder is for loosers ;-)

This is a "be awesome" exercise!

Learning goals

1. Use your imagination and all you knowledge to implement useful feature correctly.

Context

We now have a basic file tree browser displayed as Miller columns. Here's some ideas to improve it.

Ideas

• Change the style, add some textures, icons, 3D effects, transitions...
• Add a link to go to parent path.
• Don't reload the hole page for the navigation. Use AJAX. Using HTML5 History API with it would be awesome.
• Use the mimetype info, display it as text or as an icon...
• Highlight the current directory of a column.
• Preview files that can be previewed in the browser : text, images, audio, videos, pdf (using pdf.js)...
• Provide a mechanism to show/hide hidden files.
• Anything you want...

Deliveries

• public/index.php
• public/index.css
• public/index.js
• model/MillerConfig.class.php
• model/MillerPath.class.php
• model/MillerFile.class.php
• model/MillerDirectory.class.php
• view/layout.php
• view/directory.php
